The iron ore crushing and sand making production line is designed to process raw iron ore into high-quality sand and aggregates for construction, road building, and concrete applications. This system integrates crushing, screening, and sand washing technologies to maximize efficiency.
1. Primary Jaw Crusher: Processes raw iron ore (≤800mm) down to ≤200mm
– Model: PE-1200×1500
– Capacity: 400-800 t/h
– Power: 160-220 kW
2. Secondary Cone Crusher: Further reduces material to ≤50mm
– Model: HPT300
– Capacity: 180-360 t/h
– Closed-side setting: 25-60mm
3. Tertiary Impact Crusher: Produces final sand product (0-5mm)
– Model: VSI6X1263
– Capacity: 70-585 t/h
– Rotor speed: 1700-1900 rpm
| Parameter | Value |
|---|---|
| Feed size | ≤800mm |
| Final product size | 0-5mm, 5-10mm, 10-20mm |
| System capacity | 200-600 t/h |
| Power consumption | 25-30 kWh/t |
| Noise level | <75 dB(A) |
Location: Tangshan, China
Capacity: 500 t/h
Configuration:
– Primary crushing: PE1200×1500 jaw crusher
– Secondary crushing: Two HPT300 cone crushers
– Sand making: Three VSI6X1263 impact crushers
Operation results:
✔ Finished product yield ≥85%
✔ Product cube-shaped ratio ≥90%
