Dry processing plants for gold recovery offer water-free solutions ideal for arid regions. These systems prioritize efficiency through modular designs and advanced air classification technology.
1. Primary Crusher: Jaw crusher (Model JC-50, Feed size: 400mm, Capacity: 50t/h)
2. Secondary Crusher: Impact crusher (Model IC-30, Output: 0-30mm, Power: 75kW)
3. Tertiary Grinding: Vertical shaft impactor (Model VSI-20, Product fineness: 0-5mm)
4. Air Classification: Vibrating screen with air injection (Separation efficiency: ≥92%)
| Model | Throughput (t/h) | Power (kW) | Gold Recovery Rate |
|---|---|---|---|
| GDP-50 | 50 | 185 | 85-88% |
| GDP-100 | 100 | 320 | 87-90% |
| GDP-200 | 200 | 480 | 89-92% |
Q1: Dust control measures?
A: Integrated baghouse filters with ≥99% efficiency
Q2: Minimum gold particle size recoverable?
A: Down to 50 microns with optional electrostatic separation
Q3: Mobility options?
A: Skid-mounted or trailer-mounted configurations available
Location: Mauritania
Configuration:
– Primary jaw crusher
– Two-stage impact crushing
– Air jig concentration system
Results:
– Achieved 91% recovery rate
– Zero water consumption
– Commissioned within 15 days
