copper production plant from local ores

Copper Ore Crushing and Sand Making Production Line

To process local copper ores into high-quality sand and aggregates, a specialized crushing and sand-making production line is essential. The typical configuration includes:

1. Primary Jaw Crusher (PE-600×900)
– Feed size: ≤500mm
– Capacity: 50-160t/h
– Motor power: 75kW

2. Secondary Cone Crusher (HPT300)
– Max feed size: 240mm
– Capacity: 120-400t/h
– Adjustment range: 6-38mm

3. Tertiary Impact Crusher (VSI1140) for shaping
– Throughput: 180-380t/h
– Max feed size: 50mm
– Motor power: 250kW

Key Equipment Parameters

<

Q1:What’s the final product size?
A:The system can produce 0-5mm manufactured sand,5-10mm,10-20mm,and20-31.5mm aggregates.

Q2How to handle sticky copper ore?
A:A rotary scrubber should be added before crushing with water spray system.

Location:SulawesiIndonesia)
Capacity200TPH final products4specifications)

Configuration:
-Vibrating feederZSW490×110)
-Jaw crusherPE750×1060)

Equipment	Model	Capacity(t/h)	Power(kW)
Vibrating Feeder	GZD960×3800	80-160	11
Jaw Crusher	PE600×900	50-160	75
Cone Crusher	HPT300	120-400	220
Screening Machine	S5X1860-3D	–	30×2
Screw Sand Washer<td<td<td<tdLX1118<td<td60-180<td22
