A modern iron ore crusher plant integrates crushing, screening, and grinding to produce high-quality aggregates for construction and industrial use. Key equipment includes:
1. Primary Jaw Crusher: Processes raw iron ore (≤1500mm) into coarse fragments (≤350mm). Model example: PE1200×1500 with 400-800t/h capacity.
2. Secondary Cone Crusher: Further reduces material to ≤50mm. Popular choice: HPT300 with 200-500t/h output.
3. Tertiary Impact Crusher: Shapes final products (≤30mm, cubic grains). Model: VSI6X1263, producing 300-600t/h.
| Equipment | Feed Size | Output Size | Capacity (t/h) |
|---|---|---|---|
| Jaw Crusher | ≤1500mm | ≤350mm | 400-800 |
| Cone Crusher | ≤350mm | ≤50mm | 200-500 |
| VSI Crusher | ≤50mm | ≤30mm | 300-600 |
Vibrating screens (e.g., 3YK3070) classify materials into multiple grades. Dust collectors (pulse jet type) ensure EPA compliance (<20mg/m³ emission).
– Q: How to minimize wear in iron ore crushing?
A: Use manganese steel liners and regular lubrication cycles.
– Q: Energy consumption optimization?
A:> Adopt variable frequency drives (VFDs) on conveyors/crushers (~15% power savings).
A Malaysian client achieved 1,200t/d output using our configured line: PE1200×1500 jaw crusher + HST315 cone
