West Bengal faces severe environmental and infrastructural issues due to uncontrolled sand mining. To address this, modern crushing-screening plants offer eco-friendly alternatives by processing hard rocks into high-quality aggregates.
A typical 200TPH plant includes:
1. Primary Jaw Crusher (PE-600×900) – 75kW motor, ≤480mm feed size
2. Secondary Cone Crusher (HPT300) – Hydraulic adjustment, 220kW power
3. Tertiary VSI Crusher (B-9100SE) – Rock-on-rock design, 45-165tph capacity
4. Vibrating Screens (3YK3070) – Triple-deck, 22kW power
| Model | Capacity(tph) | Power(kW) | Output Size(mm) |
|---|---|---|---|
| PE-600×900 | 50-160 | 75 | 65-160 |
| HPT300 | 120-250 | 220 | 5-60 |
| B-9100SE | 45-165 | 250 | 0-5 (sand) |
Q: What’s the lifespan of wear parts?
A: Jaw plates last ~6 months, cone mantles ~4 months under normal conditions.
Q: Can it process river gravel?
A: Yes, but requires pre-screening to remove silt.
Q: Minimum required space?
A: ~50m×30m for a complete 200TPH plant.
A 150TPH plant installed in 2021 produces:
– M-Sand (0-4.75mm) for concrete
– 10-20mm aggregate for road base
Reducing illegal river mining by 40% in the region. The system features water recycling
